Description
High Aesthetic Value Restorations
Developed in collaboration with Master Giuseppe Leonetti, Orodent LUX represents the most advanced expression of aesthetics within the Era range. Designed to meet the most demanding market needs, this solution stands out for its translucency of up to 51%, delivering results of extraordinary naturalness.
Created for high aesthetic value restorations, Orodent LUX enables compromise-free results, where light, depth and chromatic performance blend harmoniously. An ideal choice for laboratories aiming for excellence, combining technological innovation and artisanal sensitivity.
Technical Specifications
Full range od thicknesses and colours
98x14 mm
- A: 3,5 mm
- B: 2,1 mm
- B: 2,1 mm
- B: 2,1 mm
- C: 4,2 mm
98x16 mm
- A: 4 mm
- B: 2,4 mm
- B: 2,4 mm
- B: 2,4 mm
- C: 4,8 mm
98x18 mm
- A: 4,5 mm
- B: 2,7 mm
- B: 2,7 mm
- B: 2,7 mm
- C: 5,4 mm
Colour specification for layer
A1
- A1 Light+ (Ename)
- A1 Light (Body)
- A1 (Body)
- A1 Dark (Body)
- A2 (Neck)
A2
- A1 (Ename)
- A2 Light (Body)
- A2 (Body)
- A2 Dark (Body)
- A3 (Neck)
A3
- A2 (Ename)
- A3 Light (Body)
- A3 (Body)
- A3 Dark (Body)
- A3,5 (Neck)
Orodent Multilayer discs can be infiltrated and characterized by brush with liquids from the Colorodent Gold and SuperColors lines. After sintering, the work can be completed using Stains mixed with glaze.
Shade selection
3 Thicknesses: 14,16,18 mm
Full elements will result more saturated, therefore in a darker colour. In these cases, we suggest to choose a less saturated shade than desired and finalize with stains after sintering.
Sintering instructions
Sintering of Resistance Furnace
Maximum thickness of works <7mm (as a reference take the maximum thickest element of the work)
| Step | Temperature | Gradient °C/min | Holding time | Duration | Total time |
|---|---|---|---|---|---|
| 0 | 30°C | - | - | - | |
| 1 | 930°C | 9°C | 30 min | 130 min | |
| 2 | 1530°C | 2.4°C | 120 min | 370 min | |
| 3 | 100°C | -9.0°C | 0 min | 160 min | |
| Total: 660 min | h 11 | ||||
Maximum thickness of the works >7mm (as a reference take the maximum thickest element of the work)
| Step | Temperature | Gradient °C/min | Holding time | Duration | Total time |
|---|---|---|---|---|---|
| 0 | 30°C | - | - | - | |
| 1 | 930°C | 9°C | 30 min | 130 min | |
| 2 | 1530°C | 1.8°C | 120 min | 453 min | |
| 3 | 100°C | -9.0°C | 0 min | 160 min | |
| Total: 743 min | h 12.4 | ||||
