Multilayer

Zirconia Orodent Lux 700/1100 MPa

Pre-order only

Clear
SKU: ZS98XXUMSYY Category:

Description

High Aesthetic Value Restorations

Developed in collaboration with Master Giuseppe Leonetti, Orodent LUX represents the most advanced expression of aesthetics within the Era range. Designed to meet the most demanding market needs, this solution stands out for its translucency of up to 51%, delivering results of extraordinary naturalness.

Created for high aesthetic value restorations, Orodent LUX enables compromise-free results, where light, depth and chromatic performance blend harmoniously. An ideal choice for laboratories aiming for excellence, combining technological innovation and artisanal sensitivity.

1000
Mpa
Flexural strength
51
%
Translucence
4
Colors
3
Heights

Technical Specifications

Full range od thicknesses and colours

A: Ename (cusp), B: Body, C: Neck

98x14 mm

  • A: 3,5 mm
  • B: 2,1 mm
  • B: 2,1 mm
  • B: 2,1 mm
  • C: 4,2 mm

98x16 mm

  • A: 4 mm
  • B: 2,4 mm
  • B: 2,4 mm
  • B: 2,4 mm
  • C: 4,8 mm

98x18 mm

  • A: 4,5 mm
  • B: 2,7 mm
  • B: 2,7 mm
  • B: 2,7 mm
  • C: 5,4 mm

Colour specification for layer

A1

  • A1 Light+ (Ename)
  • A1 Light (Body)
  • A1 (Body)
  • A1 Dark (Body)
  • A2 (Neck)

A2

  • A1 (Ename)
  • A2 Light (Body)
  • A2 (Body)
  • A2 Dark (Body)
  • A3 (Neck)

A3

  • A2 (Ename)
  • A3 Light (Body)
  • A3 (Body)
  • A3 Dark (Body)
  • A3,5 (Neck)

Orodent Multilayer discs can be infiltrated and characterized by brush with liquids from the Colorodent Gold and SuperColors lines. After sintering, the work can be completed using Stains mixed with glaze.

Shade selection

3 Thicknesses: 14,16,18 mm

A1
A2
A3
A0

Full elements will result more saturated, therefore in a darker colour. In these cases, we suggest to choose a less saturated shade than desired and finalize with stains after sintering.

Sintering instructions

Sintering of Resistance Furnace

Maximum thickness of works <7mm (as a reference take the maximum thickest element of the work)
Step Temperature Gradient °C/min Holding time Duration Total time
0 30°C - - -
1 930°C 9°C 30 min 130 min
2 1530°C 2.4°C 120 min 370 min
3 100°C -9.0°C 0 min 160 min
Total: 660 min h 11
! Oven opening temperature: <100°C
Maximum thickness of the works >7mm (as a reference take the maximum thickest element of the work)
Step Temperature Gradient °C/min Holding time Duration Total time
0 30°C - - -
1 930°C 9°C 30 min 130 min
2 1530°C 1.8°C 120 min 453 min
3 100°C -9.0°C 0 min 160 min
Total: 743 min h 12.4
! Oven opening temperature: <100°C

Additional information

Flexural strength

,

Translucency
Applications

,

Sintering

Coloring liquids

,

Category
